    Base SSG configuration for ON-STICK scheme

    Full description of on-stick mode in Configuring on-stick and LAG/LACP section
    1. Prepare the server according to the installation requirements.
    2. Install and configure the VEOS OS
    3. Set an IP address.
    4. Apply for license installation and fastDPI to Service Desk.
    5. After installing them, the following settings must be made in etc/dpi/fastdpi.conf:
      dpdk_device=port1:pci:86:00.0
dpdk_device=port2:pci:86:00.1

lag {
    name=LACP
    device=86-00.1
    device=86-00.0
    lacp=1
    system_id=6c:b3:11:60:fa:66
    priority=32768
    balance_algo=0
}

onstick_device {
    base=port1
    filter=vlan(101,102) | qinq
    subs=subs1
    inet=inet1
}

onstick_device {
    base=port2
    filter=vlan(101,102) | qinq
    subs=subs2
    inet=inet2
}

in_dev=subs1:subs2
out_dev=inet1:inet2
    6. Further settings are made depending on which components are to be used. The settings are described in the SSG components section.

    Implementation scheme
